HV Connector Caps - GPN 396

The GPN 396 high-voltage connector caps are suitable for use in parts and components for hybrid and electric vehicles. It protects plugs, e.g. in the area of batteries, DC/DC converters, on-board chargers, power strips and high-voltage distribution, against corrosion and mechanical damage and offers protection against splash water in accordance with protection class IPX4. The connector cap has non-slip gripping surfaces that allow fast removal and impresses with a functional registered design. The plastic used consists of post-consumer recycled material.

HV connector caps for external protection
Production in accordance with ISO 16232 in a specially designed cleanroom possible
Blue Angel-certified recycled material

This new series of standards is currently under development and will be available soon. The information provided is therefore provisional and subject to change. Our team will be happy to answer any questions you may have.

more advantages

100% Post-Consumer Recyclate

Dimensions

Colour

recycling blue

Material

PCR-PE

mm inch

				Dimensions
Item	A	C	H	M	CAD	Order no.
Available soon GPN 396 HV 51 PCR-PE, recycling blue	1.583 40,2	0.823 20,9	0.217 5,5	0.492 12,5	show	39605010000

Dimensions in mm

Information on materials, colours, drawings and use of our articles can be found on pages 166/167.

Application guide

mm inch


	Item	Contact connections
	Available soon GPN 396 HV 51 PCR-PE, recycling blue	HVR HVR	2 2

The article consists of 98 % PCR-PE and 2 % colour based on a PIR carrier. The plastic used consists of 100 % PCR.

For these articles, color deviations as well as black dots, which cannot be completely avoided due to production technology, are permissible. We recommend that functional tests be carried out before series production.
