Closures - GPN 900
The GPN 900 closures can be used universally as a cap or a plug and have a cylindrical closure.
- Closures for internal and external protection
- Production in accordance with ISO 16232 in a specially designed cleanroom possible
- Two sustainable variants made from post-consumer recyclate available
Dimensions
Indoor application
|
Outdoor application
|
Indoor application
|
||||||
---|---|---|---|---|---|---|---|---|
Item
|
A
|
C
|
D
|
G
|
H
|
CAD
|
Order no.
|
|
GPN 900 A 9 PCR-PE, blue | 0.433 | 0.354 | 0.291 | 0.413 | 0.374 | show | 9000090RB61 | |
|
||||||||
GPN 900 A 8,5 PCR-PE, blue | 0.472 | 0.327 | 0.236 | 0.669 | 0.63 | show | 9000085RB61 | |
|
||||||||
GPN 900 A 8,9 PCR-PE, blue | 0.472 | 0.35 | 0.228 | 0.413 | 0.374 | show | 9000089RB61 | |
|
||||||||
GPN 900 A 7 PCR-PE, blue | 0.512 | 0.283 | 0.205 | 0.413 | 0.354 | show | 9000070RB61 | |
|
||||||||
GPN 900 A 12,5 x 9,5 PCR-PE, blue | 0.591 | 0.504 | 0.445 | 0.413 | 0.374 | show | 9004315RB61 | |
|
||||||||
GPN 900 A 10,5 PCR-PE, blue | 0.63 | 0.406 | 0.315 | 0.65 | 0.61 | show | 9000105RB61 | |
|
||||||||
GPN 900 A 11 PCR-PE, blue | 0.63 | 0.425 | 0.315 | 0.669 | 0.622 | show | 9000110RB61 | |
|
||||||||
GPN 900 A 14 PCR-PE, blue | 0.669 | 0.579 | 0.461 | 0.413 | 0.374 | show | 9000140RB61 | |
|
||||||||
GPN 900 A 12 PCR-PE, blue | 0.709 | 0.472 | 0.386 | 0.441 | 0.394 | show | 9000120RB61 | |
|
||||||||
GPN 900 A 13,5 PCR-PE, blue | 0.709 | 0.528 | 0.453 | 0.394 | 0.394 | show | 9000135RB61 | |
|
||||||||
GPN 900 A 12,5 PCR-PE, blue | 0.787 | 0.488 | 0.394 | 0.693 | 0.638 | show | 9000125RB61 | |
|
||||||||
GPN 900 A 14,5 PCR-PE, blue | 0.787 | 0.571 | 0.453 | 0.831 | 0.819 | show | 9000145RB61 | |
|
||||||||
GPN 900 A 15 PCR-PE, blue | 0.787 | 0.598 | 0.504 | 0.539 | 0.5 | show | 9000150RB61 | |
|
||||||||
GPN 900 A 17 PCR-PE, blue | 0.787 | 0.669 | 0.571 | 1.004 | 0.945 | show | 9000170RB61 | |
|
||||||||
GPN 900 A 16,9 PCR-PE, blue | 0.787 | 0.669 | 0.571 | 0.413 | 0.374 | show | 9000169RB61 | |
|
||||||||
GPN 900 A 18,5 x 21 PCR-PE, blue | 0.827 | 0.724 | 0.61 | 1.024 | 0.984 | show | 9001852RB61 | |
|
||||||||
GPN 900 A 19,5 PCR-PE, blue | 0.846 | 0.76 | 0.685 | 0.413 | 0.374 | show | 9000195RB61 | |
|
||||||||
GPN 900 A 16,5 PCR-PE, blue | 0.866 | 0.654 | 0.531 | 0.866 | 0.827 | show | 9000165RB61 | |
|
||||||||
GPN 900 A 21 PCR-PE, blue | 0.866 | 0.815 | 0.697 | 0.413 | 0.374 | show | 9000210RB61 | |
|
||||||||
GPN 900 A 21 x 16 PCR-PE, blue | 0.886 | 0.827 | 0.732 | 0.63 | 0.63 | show | 9002116RB61 | |
|
||||||||
GPN 900 A 16,5 x 9 PCR-PE, blue | 0.945 | 0.654 | 0.531 | 0.413 | 0.354 | show | 9001659RB61 | |
|
||||||||
GPN 900 A 19 PCR-PE, blue | 0.984 | 0.744 | 0.65 | 0.433 | 0.413 | show | 9000190RB61 | |
|
||||||||
GPN 900 A 22,5 PCR-PE, blue | 0.984 | 0.886 | 0.776 | 0.492 | 0.472 | show | 9000225RB61 | |
|
||||||||
GPN 900 A 24,5 x 25 PCR-PE, blue | 1.024 | 0.969 | 0.846 | 1.024 | 0.984 | show | 9004322RB61 | |
|
||||||||
GPN 900 A 18,5 PCR-PE, blue | 1.102 | 0.724 | 0.61 | 1.024 | 0.984 | show | 9000185RB61 | |
|
||||||||
GPN 900 A 20 PCR-PE, blue | 1.102 | 0.795 | 0.701 | 0.846 | 0.827 | show | 9000200RB61 | |
|
||||||||
GPN 900 A 24 PCR-PE, blue | 1.102 | 0.941 | 0.799 | 1.161 | 1.142 | show | 9000240RB61 | |
|
||||||||
GPN 900 A 25,5 PCR-PE, blue | 1.102 | 1.004 | 0.878 | 0.728 | 0.669 | show | 9000255RB61 | |
|
||||||||
GPN 900 A 24,7 PCR-PE, blue | 1.142 | 0.972 | 0.909 | 1.26 | 1.24 | show | 9000247RB61 | |
|
||||||||
GPN 900 A 27 PCR-PE, blue | 1.22 | 1.063 | 0.976 | 0.858 | 0.807 | show | 9000270RB61 | |
|
||||||||
GPN 900 A 24,5 PCR-PE, blue | 1.26 | 0.965 | 0.835 | 0.413 | 0.394 | show | 9000245RB61 | |
|
||||||||
GPN 900 A 28,5 PCR-PE, blue | 1.26 | 1.118 | 1.024 | 0.394 | 0.374 | show | 9000285RB61 | |
|
||||||||
GPN 900 A 30 PCR-PE, blue | 1.299 | 1.181 | 1.075 | 0.807 | 0.748 | show | 9000300RB61 | |
|
||||||||
GPN 900 A 31 PCR-PE, blue | 1.339 | 1.22 | 1.102 | 0.413 | 0.374 | show | 9000310RB61 | |
|
||||||||
GPN 900 A 32 PCR-PE, blue | 1.417 | 1.28 | 1.165 | 0.886 | 0.827 | show | 9000320RB61 | |
|
||||||||
GPN 900 A 33 PCR-PE, blue | 1.457 | 1.291 | 1.157 | 0.787 | 0.748 | show | 9000330RB61 | |
|
||||||||
GPN 900 A 41 PCR-PE, blue | 1.693 | 1.594 | 1.476 | 0.433 | 0.374 | show | 9000410RB61 | |
|
||||||||
GPN 900 A 39 PCR-PE, blue | 1.85 | 1.528 | 1.394 | 0.866 | 0.827 | show | 9000390RB61 | |
|
||||||||
GPN 900 A 45 PCR-PE, blue | 1.969 | 1.764 | 1.63 | 0.787 | 0.748 | show | 9000450RB61 | |
|
||||||||
GPN 900 A 51 PCR-PE, blue | 2.106 | 2.008 | 1.902 | 1.004 | 0.945 | show | 9000510RB61 | |
|
||||||||
GPN 900 A 52 PCR-PE, blue | 2.146 | 2.047 | 1.929 | 0.413 | 0.374 | show | 9000520RB61 | |
|
||||||||
GPN 900 A 64 PCR-PE, blue | 2.717 | 2.52 | 2.421 | 1.201 | 1.142 | show | 9000640RB61 | |
|
||||||||
GPN 900 A 69 PCR-PE, blue | 2.835 | 2.736 | 2.618 | 1.161 | 1.142 | show | 9000690RB61 | |
|
Dimensions in mm
Information on materials, colours, drawings and use of our articles can be found on pages 166/167.
Quality advantages
More versatile.
Cylindrical closure - can be used as plug or cap.
Cleaner.
Production in accordance with VDA Band 19 and ISO 16232 in our specially equipped cleanroom on request.
More resource-saving.
The plastic used consists of 100 % recycled material.
Downloads
Alternative standard series
