Drawing dust plugs - GPN 930 Form A
Protective Dust Plugs - GPN 930 Type A
The GPN 930 Type A protective dust plugs protect open plug-in couplings, particularly the thread, from damage and dirt and have a captive design with a PE-LLD tab. The protective dust plugs have a thread and prevent the ingress or leaking of liquids within certain limits.
- Protective dust plugs for internal protection
- Also available in Type B as protective dust cap
Virgin material
Dimensions
|
Applicable for
|
Dimensions
|
||||||
|---|---|---|---|---|---|---|---|
|
Item
|
Nominal size
|
K
|
N
|
P
|
CAD
|
Order no.
|
|
| GPN 930 / 10075* PE-HD, red | DN 6 + 8 | M 28 x 2 | 3.937 | 0.787 | show | 93000750000 | |
|
|
|||||||
| GPN 930 / 10079* PE-HD, red | DN 10 + 12 | M 36 x 2 | 4.331 | 0.945 | show | 93000790000 | |
|
|
|||||||
| GPN 930 / 10030 PE-HD, red | DN 10 + 12 | M 36 x 2 | 5.315 | 1.161 | show | 93000300000 | |
|
|
|||||||
| GPN 930 / 10083* PE-HD, red | DN 16 + 20 | Rd 48 x 3 | 5.709 | 1.614 | show | 93000830000 | |
|
|
|||||||
| GPN 930 / 10087* PE-HD, red | DN 25 + 32 | Rd 70 x 3 | 7.874 | 2.165 | show | 93000870000 | |
|
|
|||||||
Dimensions in mm
Information on materials, colours, drawings and use of our articles can be found on pages 166/167.
*Eyelet of lug not slotted.
Quality advantages
Better fit.
Protects open plug-in couplings, and particularly their thread.
Seals better.
Prevents damage and contamination and provides limited sealing action.
Better.
Threaded.
