Drawing SAE sealing cap - GPN 241
SAE sealing caps - GPN 241
The GPN 241 SAE sealing caps are suitable for protecting the mating surfaces of SAE quick-connect plugs. The wider diameter of the collar prevents accidental assembly with a quick connector. The SAE connector can withstand short-term pressurisation of approx. 1 bar, depending on its surface quality.
- SAE sealing caps for external protection
- Production in accordance with ISO 16232 in a specially designed cleanroom possible
100% Post-Consumer Recyclate
Recycling blend
Virgin material
Dimensions
|
Applicable for
|
Dimensions
|
||||||
|---|---|---|---|---|---|---|---|
|
Item
|
SAE-Plug NW
|
A
|
D
|
G
|
CAD
|
Order no.
|
|
| GPN 241 DF 10, yellow | 0.394 | 0.709 | 0.382 | 0.886 | show | 24100100073 | |
|
|
|||||||
| GPN 241 DF 12,7, yellow | 0.500 | 0.787 | 0.492 | 0.925 | show | 24101270073 | |
|
|
|||||||
| GPN 241 DF 16, yellow | 0.630 | 0.945 | 0.608 | 0.945 | show | 24100160073 | |
|
|
|||||||
| GPN 241 DF 18, yellow | 0.709 | 0.984 | 0.701 | 0.827 | show | 24100180073 | |
|
|
|||||||
| GPN 241 DF 8*, yellow | 0.315 | 0.63 | 0.307 | 0.705 | show | 24100080073 | |
|
|
|||||||
| GPN 241 DF 9,5, yellow | 0.374 | 0.669 | 0.37 | 0.748 | show | 24100950073 | |
|
|
|||||||
Dimensions in mm
Information on materials, colours, drawings and use of our articles can be found on pages 166/167.
*This size is supplied with inner ribs.
Quality advantages
Better fit.
For protecting the mating surfaces of SAE quick-connect plugs.
Seals better.
Depending on the surface quality of the SAE plug, a short-term pressurisation of approx. 1 bar is possible.
Cleaner.
Production in accordance with VDA Band 19 and ISO 16232 in our specially equipped cleanroom on request.
Better.
Diameter A prevents the inadvertent assembly with a quick connector.
