Screw-in Plugs - GPN 551
The GPN 551 screw-in plugs offer threads and drill holes protection against dirt and damage and are particularly suitable for painting. The thick-walled shaft self-taps into a thread. The conical shape of the screw-in plugs enables tolerances to be accommodated. The material is temporarily heat-resistant up to 180°C.
- Screw-in plugs for internal protection
- Temporarily heat-resistant up to 180°C
Dimensions
![Drawing Insertion elements - GPN 551 Drawing Insertion elements - GPN 551](/us/dam/jcr:18d0b338-66eb-4ea7-9581-bffb809138fa/gpn-551-eindrehelemente-cad-web.png)
Applicable for
|
Dimensions
|
||||||||
---|---|---|---|---|---|---|---|---|---|
Item
|
Thread type
|
A
|
B
|
C
|
H
|
M
|
CAD
|
Order no.
|
|
GPN 551 / 002 PHT / TPC-ET, red | M 2 | 0.276 | 0.051 | 0.079 | 0.276 | 0.551 | show | 55100020000 | |
|
|||||||||
GPN 551 / 003 PHT / TPC-ET, red | M 3 | 0.276 | 0.083 | 0.118 | 0.472 | 0.748 | show | 55100030000 | |
|
|||||||||
GPN 551 / 004 PHT / TPC-ET, red | M 4 | 0.315 | 0.11 | 0.157 | 0.591 | 0.866 | show | 55100040000 | |
|
|||||||||
GPN 551 / 005 PHT / TPC-ET, red | M 5 | 0.354 | 0.142 | 0.197 | 0.709 | 1.063 | show | 55100050000 | |
|
|||||||||
GPN 551 / 006 PHT / TPC-ET, red | M 6 | 0.433 | 0.169 | 0.228 | 0.709 | 1.063 | show | 55100060000 | |
|
|||||||||
GPN 551 / 007 PHT / TPC-ET, red | M 7 | 0.413 | 0.197 | 0.256 | 0.709 | 1.063 | show | 55100070000 | |
|
|||||||||
GPN 551 / 008 PHT / TPC-ET, red | M 8 | 0.551 | 0.236 | 0.295 | 0.709 | 1.063 | show | 55100080000 | |
|
|||||||||
GPN 551 / 009 PHT / TPC-ET, red | M 9 | 0.551 | 0.256 | 0.335 | 0.709 | 1.063 | show | 55100090000 | |
|
|||||||||
GPN 551 / 010 PHT / TPC-ET, red | M 10 | 0.63 | 0.299 | 0.366 | 0.827 | 1.181 | show | 55100100000 | |
|
|||||||||
GPN 551 / 012 PHT / TPC-ET, red | M 12 | 0.709 | 0.366 | 0.433 | 0.827 | 1.181 | show | 55100120000 | |
|
Dimensions in mm
Information on materials, colours, drawings and use of our articles can be found on pages 166/167.
