Screw Plugs - GPN 720 Type B
The GPN 720 Type B screw plugs are suitable for many different internal threads. The sealing cone prevents the ingress or leaking of liquids within certain limits.
- Screw Plugs for internal protection
- Also available in Type A in a thick-walled design
- Two sustainable variants made from post-consumer recyclate available
Dimensions
![Drawing screw plug - GPN 720 Form B Drawing screw plug - GPN 720 Form B](/us/dam/jcr:0c80be1e-4b8a-420d-a02c-9032c8723085/gpn-720-b-verschlussschrauben-cad-web.png)
Applicable for
|
Dimensions
|
|||||
---|---|---|---|---|---|---|
Item
|
K
|
H
|
SW
|
CAD
|
Order no.
|
|
GPN 720 / 0232 PCR-PE / PE-LD, yellow | M 16 x 1.5 | 0.551 | 8 | show | 72002320073 | |
|
||||||
GPN 720 / 1668 PCR-PE / PE-LD, yellow | M 20 x 1.5 | 0.685 | 13 | show | 72016680073 | |
|
||||||
GPN 720 / 1763 PCR-PE / PE-LD, yellow | M 18 x 1.5 | 0.524 | 10 | show | 72017630073 | |
|
||||||
GPN 720 / 9463 PCR-PE / PE-LD, yellow | M 10 x 1 | 0.441 | 5 | show | 72094630073 | |
|
Dimensions in mm
Information on materials, colours, drawings and use of our articles can be found on pages 166/167.
Quality advantages
![<p><strong>Seals better.<strong></p>](/us/dam/jcr:c20cccd8-6a3c-4552-9204-8cc70d026b2f/kapsto-icon-abdichtend.png)
Seals better.
Depending on the application, the sealing cone will prevent penetration or leaking of liquids.
![<p><strong>Better.</strong></p>](/us/dam/jcr:720816ac-c80b-4454-9754-37b505968675/kapsto-icon-zusatzinformationen.png)
Better.
Immersible screw plug with hexagonal socket.
![<p><strong>More resource-saving.</strong></p>](/us/dam/jcr:a3ea48bd-a0a3-47f4-9a51-b6ec6a585aaa/kapsto-icon-ressourcenschonender.png)
More resource-saving.
Mix of post-consumer recyclate and virgin material
