Drawing quick release fasteners - GPN 940
Fast-fit Caps - GPN 940
The GPN 940 fast-fit caps are tamper-evident closures for valves according to DIN 477-1 and are also suitable for external threads and bolts. They have a ventilation tab for safe leakage. The easy-to-grip ring lug and tear lines ensure fast removal.
- Fast-fit caps for external protection
- Two sustainable variants made from post-consumer recyclate available
100% Post-Consumer Recyclate
Dimensions
Colour
yellow
Material
PCR-PE / PE-LD
Technical data sheet
|
Applicable for
|
Dimensions
|
||||||
|---|---|---|---|---|---|---|---|
|
Item
|
External thread
|
D
|
G
|
N
|
CAD
|
Order no.
|
|
| GPN 940 SV 26 PCR-PE / PE-LD, yellow | G 3/4 | 26 | 14,5 | 36,8 | show | 94002600073 | |
|
|
|||||||
| GPN 940 SV 21,3 PCR-PE / PE-LD, yellow | W 21,80 x 1/14 | 21,3 | 14,5 | 34 | show | 94002130073 | |
|
|
|||||||
| GPN 940 SV 23,9 PCR-PE / PE-LD, yellow | W 24,32 x 1/14 | 23,9 | 14,5 | 35 | show | 94002390073 | |
|
|
|||||||
Dimensions in mm.
Information on materials, colours, designs and use of our products can be found on the website and in chapter 3´ Materials and application´.
Quality advantages
Better fit.
Tamper-evident closure for valves in accordance with DIN 477-1.
Saves time.
Particularly fast and easy to remove.
Better.
With ventilation tab for safe leakage. Also suitable for external threads and studs.
More resource-saving.
Blend of post-consumer recyclate and virgin material
Downloads
Alternative standard series
