Application protective sleeves - GPN 207
drawing Protective sleeves - GPN 207
Protective Caps with Fins - GPN 207
The GPN 207 protective caps are suitable for bolts, pins and external threads as well as SAE connectors. Internal fins are suitable for use with different diameters. Spacing between the fins enables ventilation.
- Protective caps for external protection
- Production in accordance with ISO 16232 in a specially designed cleanroom possible
- Two sustainable variants made from post-consumer recyclate available
100% Post-Consumer Recyclate
Recycling blend
Virgin material
Dimensions
Colour
blue
Material
PCR-PE
Technical data sheet
|
Applicable for
|
Dimensions
|
||||||||
|---|---|---|---|---|---|---|---|---|---|
|
Item
|
SAE-Plug NW
|
E min
|
E max
|
A
|
D
|
G
|
CAD
|
Order no.
|
|
| GPN 207 FL 73 PCR-PE, blue | 5,8 | 7,3 | 13 | 9 | 25 | show | 2070073RB61 | ||
|
|
|||||||||
| GPN 207 FL 107 PCR-PE, blue | 7,8 | 10,7 | 17 | 13,5 | 25 | show | 2070107RB61 | ||
|
|
|||||||||
| GPN 207 FL 67 PCR-PE, blue | 6,35 (1/4'') | 5,2 | 6,7 | 12 | 8 | 25 | show | 2070067RB61 | |
|
|
|||||||||
| GPN 207 FL 77 PCR-PE, blue | 7,89 (5/16'') | 6,5 | 7,7 | 14 | 10 | 32 | show | 2070077RB61 | |
|
|
|||||||||
| GPN 207 FL 80 PCR-PE, blue | 7,89 (5/16'') | 6,5 | 8 | 14 | 10 | 20 | show | 2070080RB61 | |
|
|
|||||||||
| GPN 207 FL 123 PCR-PE, blue | 9,49 (3/8'') | 9,89 (7/16'') | 9,3 | 12,3 | 18,5 | 14,3 | 23 | show | 2070123RB61 | |
|
|
|||||||||
| GPN 207 FL 150 PCR-PE, blue | 12,70 (1/2'') | 11,8 | 15 | 21 | 17,3 | 25 | show | 2070150RB61 | |
|
|
|||||||||
Dimensions in mm.
Information on materials, colours, designs and use of our products can be found on the website and in chapter 3´ Materials and application´.
Application guide
|
Item
|
Pipe thread
|
metric male thread
|
|
|---|---|---|---|
| GPN 207 FL 67 PCR-PE, blue | |||
| GPN 207 FL 77 PCR-PE, blue | |||
| GPN 207 FL 73 PCR-PE, blue | M 6 | ||
| GPN 207 FL 80 PCR-PE, blue | M 8 | ||
| GPN 207 FL 107 PCR-PE, blue | M 8 | M 10 | ||
| GPN 207 FL 150 PCR-PE, blue | G 1/4 | M 12 | M 14 | |
| GPN 207 FL 123 PCR-PE, blue | G 1/8 | M 10 | |
This application table represents guideline values. We would be pleased to send you free samples.
Quality advantages
More versatile.
Suitable for different diameters due to flexible internal fins.
Cleaner.
Production in accordance with VDA Band 19 and ISO 16232 in our cleanroom on request.
Better.
Internal fins providing venting and pressure equalisation. Suitable for studs, pins, external threads and the mating surfaces of SAE quick-connect plugs.
More resource-saving.
The plastic used consists of 100 % recycled material.
