Application Dust plugs - GPN 920 Form B
Drawing dust plugs - GPN 920 Form B
Protective Dust Plugs - GPN 920 Type B
The GPN 920 Type B protective dust caps protect open plug-in couplings against damage and dirt and feature a captive tab design. The protective dust caps prevent the ingress or leaking of liquids within certain limits.
- Protective dust caps for external protection
- Two sustainable variants made from post-consumer recyclate available
100% Post-Consumer Recyclate
Recycling blend
Dimensions
Colour
red
Material
PCR-PE / PE-LD
Technical data sheet
|
Applicable for
|
Dimensions
|
|||||||
|---|---|---|---|---|---|---|---|---|
|
Item
|
Nominal size
|
D
|
E
|
N
|
P
|
CAD
|
Order no.
|
|
| GPN 920 / 4984 PCR-PE / PE-LD, red | 1/2 | 24 | 23 | 135 | 29 | show | 92049840073 | |
|
|
||||||||
| GPN 920 / 5371 PCR-PE / PE-LD, red | 1/2 | 24 | 23 | 135 | 27 | show | 92053710073 | |
|
|
||||||||
| GPN 920 / 9997 PCR-PE / PE-LD, red | 1/4 | 12,5 | 11,5 | 125 | 22 | show | 92099970073 | |
|
|
||||||||
| GPN 920 / 9995 PCR-PE / PE-LD, red | 3/8 | 18,5 | 16 | 125 | 22 | show | 92099950073 | |
|
|
||||||||
Dimensions in mm.
Information on materials, colours, designs and use of our products can be found on the website and in chapter 3´ Materials and application´.
Quality advantages
Better fit.
Protects open plug-in couplings from damage and contamination.
Seals better.
Prevents damage and contamination and provides limited sealing action.
Better.
Self-retaining design due to integral strap.
More resource-saving.
Blend of post-consumer recyclate and virgin material
