Drawing screw cap with sealing washer
Screw Caps with Sealing Disc - GPN 802
The GPN 802 screw caps with sealing disc are suitable for many different thread types, such as metric threads, pipe threads and imperial threads. The screw cap features a sealing disc made of nitrile butadiene rubber (NBR), which meets increased demands on leak tightness. Easy-to-grip external ribs for easy fitting by hand.
- Screw caps with sealing disc for external protection
Virgin material
Dimensions
Colour
yellow
Material
PE-HD
Technical data sheet
Colour
Standardfarbe Dichtscheibe: schwarz
Sealing material
Material Dichtscheibe: NBR (70 +/- 5 Shore A)
|
Applicable for
|
Dimensions
|
|||||
|---|---|---|---|---|---|---|
|
Item
|
L
|
A
|
G
|
CAD
|
Order no.
|
|
| GPN 802 1 - 14 UNS PE-HD, yellow | 1 - 14 UNS | 33 | 14 | show | 80272100000 | |
|
|
||||||
| GPN 802 1 1/16 - 12 UN PE-HD, yellow | 1 1/16 - 12 UN | 34 | 23 | show | 80259460000 | |
|
|
||||||
| GPN 802 1 1/16 - 16 UN PE-HD, yellow | 1 1/16 - 16 UN | 34 | 14 | show | 80272120000 | |
|
|
||||||
| GPN 802 1 1/4 - 12 UNF PE-HD, yellow | 1 1/4 - 12 UNF | 38 | 14 | show | 80272150000 | |
|
|
||||||
| GPN 802 1 3/16 - 20 UN PE-HD, yellow | 1 3/16 - 20 UN | 38 | 14 | show | 80272140000 | |
|
|
||||||
| GPN 802 1 5/16 - 12 UN PE-HD, yellow | 1 5/16 - 12 UN | 40 | 24 | show | 80259450000 | |
|
|
||||||
| GPN 802 1 5/8 - 12 UN PE-HD, yellow | 1 5/8 - 12 UN | 50 | 17 | show | 80272170000 | |
|
|
||||||
| GPN 802 1 7/8 - 12 UN PE-HD, yellow | 1 7/8 - 12 UN | 55 | 17 | show | 80272210000 | |
|
|
||||||
| GPN 802 1/2 - 20 UNF PE-HD, yellow | 1/2 - 20 UNF | 18 | 15 | show | 80259500000 | |
|
|
||||||
| GPN 802 1/4 - 28 UNF PE-HD, yellow | 1/4 - 28 UNF | 12 | 8 | show | 80272070000 | |
|
|
||||||
| GPN 802 13/16 - 16 UN PE-HD, yellow | 13/16 - 16 UN | 26 | 12 | show | 80231600000 | |
|
|
||||||
| GPN 802 2 1/2 - 12 UN PE-HD, yellow | 2 1/2 - 12 UN | 72 | 18 | show | 80272260000 | |
|
|
||||||
| GPN 802 2 1/4 - 12 UN PE-HD, yellow | 2 1/4 - 12 UN | 66 | 18 | show | 80272250000 | |
|
|
||||||
| GPN 802 3/4 - 16 UNF PE-HD, yellow | 3/4 - 16 UNF | 24 | 18 | show | 80259480000 | |
|
|
||||||
| GPN 802 5/8 - 18 UNF PE-HD, yellow | 5/8 - 18 UNF | 19,3 | 14,2 | show | 80231820000 | |
|
|
||||||
| GPN 802 7/16 - 20 UNF PE-HD, yellow | 7/16 - 20 UNF | 15 | 12 | show | 80264550000 | |
|
|
||||||
| GPN 802 7/8 - 14 UNF PE-HD, yellow | 7/8 - 14 UNF | 27 | 20 | show | 80259470000 | |
|
|
||||||
| GPN 802 9/16 - 18 UNF PE-HD, yellow | 9/16 - 18 UNF | 18 | 12 | show | 80264560000 | |
|
|
||||||
| GPN 802 G 1 1/2 PE-HD, yellow | G 1 1/2 | 56 | 17 | show | 80275520000 | |
|
|
||||||
| GPN 802 G 1 1/4 PE-HD, yellow | G 1 1/4 | 47,7 | 17,7 | show | 80232180000 | |
|
|
||||||
| GPN 802 G 1 PE-HD, yellow | G 1 | 39 | 14 | show | 80235220000 | |
|
|
||||||
| GPN 802 G 1/2 PE-HD, yellow | G 1/2 | 25 | 14 | show | 80204370000 | |
|
|
||||||
| GPN 802 G 1/4 PE-HD, yellow | G 1/4 | 18 | 12 | show | 80203550000 | |
|
|
||||||
| GPN 802 G 1/8 PE-HD, yellow | G 1/8 | 14 | 8 | show | 80204140000 | |
|
|
||||||
| GPN 802 G 2 1/2 PE-HD, yellow | G 2 1/2 | 80,9 | 18 | show | 80232190000 | |
|
|
||||||
| GPN 802 G 2 PE-HD, yellow | G 2 | 68 | 18 | show | 80269010000 | |
|
|
||||||
| GPN 802 G 3/4 PE-HD, yellow | G 3/4 | 32 | 14 | show | 80236180000 | |
|
|
||||||
| GPN 802 G 3/8 PE-HD, yellow | G 3/8 | 21 | 12 | show | 80204260000 | |
|
|
||||||
| GPN 802 G 5/8 PE-HD, yellow | G 5/8 | 28 | 14 | show | 80206750000 | |
|
|
||||||
| GPN 802 M 8 PE-HD, yellow | M 8 | 12 | 8 | show | 80200080000 | |
|
|
||||||
| GPN 802 M 8 x 1 PE-HD, yellow | M 8 x 1 | 12 | 8 | show | 80208100000 | |
|
|
||||||
| GPN 802 M 10 PE-HD, yellow | M 10 | 14,5 | 8 | show | 80200100000 | |
|
|
||||||
| GPN 802 M 10 x 1 PE-HD, yellow | M 10 x 1 | 14 | 8 | show | 80210100000 | |
|
|
||||||
| GPN 802 M 12 PE-HD, yellow | M 12 | 16 | 12 | show | 80200120000 | |
|
|
||||||
| GPN 802 M 12 x 1 PE-HD, yellow | M 12 x 1 | 16 | 12 | show | 80212100000 | |
|
|
||||||
| GPN 802 M 12 x 1,5 PE-HD, yellow | M 12 x 1,5 | 16 | 12 | show | 80212150000 | |
|
|
||||||
| GPN 802 M 14 PE-HD, yellow | M 14 | 18 | 12 | show | 80200140000 | |
|
|
||||||
| GPN 802 M 14 x 1,5 PE-HD, yellow | M 14 x 1,5 | 18 | 12 | show | 80214150000 | |
|
|
||||||
| GPN 802 M 16 PE-HD, yellow | M 16 | 21 | 12 | show | 80200160000 | |
|
|
||||||
| GPN 802 M 16 x 1,5 PE-HD, yellow | M 16 x 1,5 | 21 | 12 | show | 80216150000 | |
|
|
||||||
| GPN 802 M 18 PE-HD, yellow | M 18 | 22 | 12 | show | 80200180000 | |
|
|
||||||
| GPN 802 M 18 x 1,5 PE-HD, yellow | M 18 x 1,5 | 22 | 12 | show | 80218150000 | |
|
|
||||||
| GPN 802 M 20 PE-HD, yellow | M 20 | 25 | 14 | show | 80200200000 | |
|
|
||||||
| GPN 802 M 20 x 1,5 PE-HD, yellow | M 20 x 1,5 | 25 | 14 | show | 80220150000 | |
|
|
||||||
| GPN 802 M 22 PE-HD, yellow | M 22 | 28 | 14 | show | 80200220000 | |
|
|
||||||
| GPN 802 M 22 x 1,5 PE-HD, yellow | M 22 x 1,5 | 28 | 14 | show | 80222150000 | |
|
|
||||||
| GPN 802 M 22 x 2 PE-HD, yellow | M 22 x 2 | 28 | 14 | show | 80222200000 | |
|
|
||||||
| GPN 802 M 23 x 1,5 PE-HD, yellow | M 23 x 1,5 | 29 | 22 | show | 80223150000 | |
|
|
||||||
| GPN 802 M 24 PE-HD, yellow | M 24 | 32 | 14 | show | 80200240000 | |
|
|
||||||
| GPN 802 M 24 x 1,5 PE-HD, yellow | M 24 x 1,5 | 30 | 14 | show | 80224150000 | |
|
|
||||||
| GPN 802 M 25 x 1,5 PE-HD, yellow | M 25 x 1,5 | 33 | 14 | show | 80225150000 | |
|
|
||||||
| GPN 802 M 26 x 1,5 PE-HD, yellow | M 26 x 1,5 | 34 | 11 | show | 80226150000 | |
|
|
||||||
| GPN 802 M 27 PE-HD, yellow | M 27 | 35 | 14 | show | 80200270000 | |
|
|
||||||
| GPN 802 M 28 x 1,5 PE-HD, yellow | M 28 x 1,5 | 34,5 | 28 | show | 80228150000 | |
|
|
||||||
| GPN 802 M 30 PE-HD, yellow | M 30 | 38 | 14 | show | 80200300000 | |
|
|
||||||
| GPN 802 M 30 x 1,5 PE-HD, yellow | M 30 x 1,5 | 36 | 14 | show | 80230150000 | |
|
|
||||||
| GPN 802 M 30 x 2 PE-HD, yellow | M 30 x 2 | 38 | 14 | show | 80230200000 | |
|
|
||||||
| GPN 802 M 36 x 1,5 PE-HD, yellow | M 36 x 1,5 | 44 | 17 | show | 80236150000 | |
|
|
||||||
| GPN 802 M 36 x 2 PE-HD, yellow | M 36 x 2 | 44 | 17 | show | 80236200000 | |
|
|
||||||
| GPN 802 M 42 x 2 PE-HD, yellow | M 42 x 2 | 50 | 15 | show | 80242200000 | |
|
|
||||||
| GPN 802 M 45 x 1,5 PE-HD, yellow | M 45 x 1,5 | 53 | 15 | show | 80245150000 | |
|
|
||||||
| GPN 802 M 45 x 2 PE-HD, yellow | M 45 x 2 | 53 | 15 | show | 80245200000 | |
|
|
||||||
| GPN 802 M 52 x 2 PE-HD, yellow | M 52 x 2 | 60 | 15 | show | 80252200000 | |
|
|
||||||
Dimensions in mm.
Information on materials, colours, designs and use of our products can be found on the website and in chapter 3´ Materials and application´.
Engraving corresponds to standard series GPN 800.
Quality advantages
Seals better.
Same design as GPN 800 but with sealing disc for increased sealing propertiers.
Better.
Suitable for a variety of different thread types. Easy to grip external rib for easy assembly and removal by hand.
More resource-saving.
The plastic used consists of 100 % recycled material.
Better fit.
Protection for High Voltage Connector Systems using our registered design.
