Tapered Plugs - GPN 607
The GPN 607 grip plugs are suitable for the protection of bore holes and internal threads, are ideal for painting and are temporarily heat-resistant up to 250°C. The handy tab guarantees fast removal and the circumferential ribs prevent the ingress of liquids within certain limits. The conical-shaped design means that the grip plugs can accommodate larger tolerances.
- Grip plugs for internal protection
- Temporarily extremely heat-resistant up to 250°C
Dimensions
![Drawing taper plug - GPN 607 Drawing taper plugs - GPN 607](/en/dam/jcr:925e847f-b2f4-4d93-9044-c4a1e7c05451/gpn-607-kegelstopfen-cad-web.png)
Dimensions
|
|||||||
---|---|---|---|---|---|---|---|
Item
|
B
|
C
|
H
|
M
|
CAD
|
Order no.
|
|
GPN 607 / 0204 | 2 | 4 | 19,5 | 35,2 | show | 60702040000 | |
|
|||||||
GPN 607 / 0406 | 4 | 6 | 25,4 | 43,2 | show | 60704060000 | |
|
|||||||
GPN 607 / 0608 | 6 | 8 | 25,4 | 43,1 | show | 60706080000 | |
|
|||||||
GPN 607 / 0810 | 8 | 10,5 | 25,4 | 43 | show | 60708100000 | |
|
|||||||
GPN 607 / 1012 | 9,8 | 11,5 | 25,4 | 43,5 | show | 60710120000 | |
|
|||||||
GPN 607 / 1214 | 11,9 | 14,5 | 25,4 | 42,5 | show | 60712140000 | |
|
|||||||
GPN 607 / 1416 | 14 | 16 | 25,4 | 42,5 | show | 60714160000 | |
|
|||||||
GPN 607 / 1618 | 16 | 18 | 25,4 | 42,5 | show | 60716180000 | |
|
|||||||
GPN 607 / 1820 | 18 | 20 | 26 | 43 | show | 60718200000 | |
|
|||||||
GPN 607 / 2022 | 20 | 22,5 | 25,4 | 43 | show | 60720220000 | |
|
|||||||
GPN 607 / 2224 | 22,5 | 24 | 25,4 | 43 | show | 60722240000 | |
|
|||||||
GPN 607 / 2426 | 24 | 26 | 25,4 | 43 | show | 60724260000 | |
|
|||||||
GPN 607 / 2628 | 25,7 | 28 | 25,4 | 43 | show | 60726280000 | |
|
|||||||
GPN 607 / 2832 | 28,6 | 32 | 25,4 | 43,8 | show | 60728320000 | |
|
Dimensions in mm.
Information on materials, colours, designs and use of our products can be found on the website and in Chapter 4 Materials and use.
Application guide
for metric threads
|
||||||||
---|---|---|---|---|---|---|---|---|
Item
|
fine thread
|
Standard thread
|
Pipe thread
|
Unified thread
|
||||
GPN 607 / 0204 | M 4 | |||||||
GPN 607 / 0406 | M 6 x 0,75 | M 6 | ||||||
GPN 607 / 0608 | M 8 x 1 | M 8 | 5/16 | |||||
GPN 607 / 0810 | M 10 x 1 | M 10 | 1/8 | 3/8 | ||||
GPN 607 / 1012 | M 12 x 1 | M 12 x 1,5 | M 12 | 7/16 | ||||
GPN 607 / 1214 | M 14 x 1,5 | M 14 | 1/4 | 1/2 | ||||
GPN 607 / 1416 | M 14 x 1 M 16 x1 | M 16 x 1,5 | M 16 | 3/8 | 9/16 5/8 | |||
GPN 607 / 1618 | M 18 x 1 | M 18 x 1,5 | M 18 | 3/4 | ||||
GPN 607 / 1820 | M 20 x 1,5 | M 20 | 1/2 | |||||
GPN 607 / 2022 | M 22 x 1,5 | M 22 | 1/2 5/8 | 7/8 | ||||
GPN 607 / 2224 | M 24 x 1,5 | M 24 x 2 | M 24 | 1 | ||||
GPN 607 / 2426 | M 26 x 1,5 | M 26 | 3/4 | 1 1 1/16 | ||||
GPN 607 / 2628 | M 28 x 1,5 | M 28 x 2 | M 28 M 30 | |||||
GPN 607 / 2832 | M 30 x 1,5 M 32 x 1,5 | M 32 x 2 | M 32 | 7/8 |
This application table is a guide. We will be happy to send you free test samples. For openings and bores without threads, please select according to functional dimensions B and C.
Clear burrs as well as partial foreign particles are permissible with these articles. We recommend that functional tests be carried out before series production.
