Application Sealing plug- GPN 736
Drawing sealing plugs - GPN 736
Sealing Screw Plugs - GPN 736
The GPN 736 sealing screw plugs are suitable for closing screw holes as per DIN 3852-1 and ISO 11926 and are particularly well suited for processes like cleaning, testing, painting, or for transport. The sturdy material is of high quality and is particularly impact-resistant. The circumferential sealing lip, which is designed without a mould seam, prevents the ingress or leaking of liquids within certain limits. To be fitted with a screwdriver or wrench.
- Sealing plugs for internal protection
Virgin material
Dimensions
Colour
yellow
Material
PA 6, PA 6PA 6
Technical data sheet
|
Applicable for
|
Dimensions
|
|||||||
|---|---|---|---|---|---|---|---|---|
|
Item
|
K
|
A
|
H
|
M
|
SW
|
CAD
|
Order no.
|
|
| GPN 736 1 1/16-12 UN PA 6, yellow | 1 1/16 - 12 UN | 37,85 | 15 | 25 | 19 | show | 73626710000 | |
|
|
||||||||
| GPN 736 1 5/16-12 UN PA 6, yellow | 1 5/16 - 12 UN | 44,8 | 15 | 25 | 24 | show | 73626720000 | |
|
|
||||||||
| GPN 736 1 5/8-12 UN PA 6, yellow | 1 5/8 - 12 UN | 55,8 | 15 | 26 | 30 | show | 73626730000 | |
|
|
||||||||
| GPN 736 1 7/8-12 UN PA 6PA 6, yellow | 1 7/8 - 12 UN | 63,3 | 15 | 26 | 30 | show | 73626740000 | |
|
|
||||||||
| GPN 736 3/4-16 UNF PA 6, yellow | 3/4 - 16 UNF | 26,9 | 11 | 21 | 13 | show | 73626690000 | |
|
|
||||||||
| GPN 736 7/16-20 UNF PA 6, yellow | 7/16 - 20 UNF | 17,4 | 9 | 16 | 10 | show | 73626670000 | |
|
|
||||||||
| GPN 736 7/8-14 UNF PA 6, yellow | 7/8 - 14 UNF | 30,4 | 13 | 23 | 15 | show | 73626700000 | |
|
|
||||||||
| GPN 736 9/16-18 UNF PA 6PA 6, yellow | 9/16 - 18 UNF | 21,4 | 10 | 18 | 10 | show | 73626680000 | |
|
|
||||||||
| GPN 736 M 10 x 1 PA 6, yellow | M 10 x 1 | 15,4 | 8 | 15 | 7 | show | 73610100000 | |
|
|
||||||||
| GPN 736 M 12 x 1,5 PA 6, yellow | M 12 x 1,5 | 18,4 | 9 | 16 | 10 | show | 73612150000 | |
|
|
||||||||
| GPN 736 M 14 x 1,5 PA 6, yellow | M 14 x 1,5 | 20,4 | 9 | 17 | 10 | show | 73614150000 | |
|
|
||||||||
| GPN 736 M 16 x 1,5 PA 6, yellow | M 16 x 1,5 | 23,4 | 10 | 20 | 13 | show | 73616150000 | |
|
|
||||||||
| GPN 736 M 18 x 1,5 PA 6, yellow | M 18 x 1,5 | 25,4 | 11 | 21 | 13 | show | 73618150000 | |
|
|
||||||||
| GPN 736 M 22 x 1,5 PA 6PA 6, yellow | M 22 x 1,5 | 28,4 | 12 | 22 | 15 | show | 73622150000 | |
|
|
||||||||
| GPN 736 M 27 x 2 PA 6, yellow | M 27 x 2 | 33,35 | 15 | 25 | 19 | show | 73627200000 | |
|
|
||||||||
| GPN 736 M 33 x 2 PA 6, yellow | M 33 x 2 | 42,3 | 15 | 25 | 24 | show | 73633200000 | |
|
|
||||||||
| GPN 736 M 42 x 2 PA 6, yellow | M 42 x 2 | 51,3 | 15 | 26 | 24 | show | 73642200000 | |
|
|
||||||||
| GPN 736 M 48 x 2 PA 6, yellow | M 48 x 2 | 56,3 | 17 | 28 | 30 | show | 73648200000 | |
|
|
||||||||
Dimensions in mm.
Information on materials, colours, designs and use of our products can be found on the website and in chapter 3´ Materials and application´.
Quality advantages
Better fit.
Suitable for internal threads in accordance with DIN 3852-1, ISO 11926.
Seals better.
The circumferential sealing lip (no mould-parting feature) prevents the penetration or leaking of liquids depending on the application.
More robust.
Made from premium impact-resistant polyamide.
Better.
Installation either with screw driver or spanner. Particularly suitable for processes like cleaning, testing, painting, or for transport.
