Application SAE sealing caps - GPN 241
Drawing SAE sealing cap - GPN 241
SAE sealing caps - GPN 241
The GPN 241 SAE sealing caps are suitable for protecting the mating surfaces of SAE quick-connect plugs. The wider diameter of the collar prevents accidental assembly with a quick connector. The SAE connector can withstand short-term pressurisation of approx. 1 bar, depending on its surface quality.
- SAE sealing caps for external protection
- Production in accordance with ISO 16232 in a specially designed cleanroom possible
100% Post-Consumer Recyclate
Recycling blend
Virgin material
Dimensions
Colour
yellow
Material
PCR-PE / PE-LD
Technical data sheet
|
Applicable for
|
Dimensions
|
||||||
|---|---|---|---|---|---|---|---|
|
Item
|
SAE-Plug NW
|
A
|
D
|
G
|
CAD
|
Order no.
|
|
| GPN 241 DF 8* PCR-PE / PE-LD, yellow | 8 | 16 | 7,8 | 17,9 | show | 24100080073 | |
|
|
|||||||
| GPN 241 DF 9,5 PCR-PE / PE-LD, yellow | 9,5 | 17 | 9,4 | 19 | show | 24100950073 | |
|
|
|||||||
| GPN 241 DF 10 PCR-PE / PE-LD, yellow | 10 | 18 | 9,7 | 22,5 | show | 24100100073 | |
|
|
|||||||
| GPN 241 DF 12,7 PCR-PE / PE-LD, yellow | 12,7 | 20 | 12,5 | 23,5 | show | 24101270073 | |
|
|
|||||||
| GPN 241 DF 16 PCR-PE / PE-LD, yellow | 16 | 24 | 15,45 | 24 | show | 24100160073 | |
|
|
|||||||
| GPN 241 DF 18 PCR-PE / PE-LD, yellow | 18 | 25 | 17,8 | 21 | show | 24100180073 | |
|
|
|||||||
Dimensions in mm.
Information on materials, colours, designs and use of our products can be found on the website and in chapter 3´ Materials and application´.
*This size is supplied with inner ribs.
Quality advantages
Better fit.
For protecting the mating surfaces of SAE quick-connect plugs.
Seals better.
Depending on the surface quality of the SAE plug, a short-term pressurisation of approx. 1 bar is possible.
Cleaner.
Production in accordance with VDA Band 19 and ISO 16232 in our cleanroom on request.
Better.
Diameter A prevents the inadvertent assembly with a quick connector.
