FAMAC® STANDARDPROGRAMME

AE-series | weld spouts for flexible packaging

Stand-up pouches replace existing packaging for pet and baby food, cleaning and laundry products, personal care and dairy products: easy to handle, light weight and reducing waste volume. With our Pouchbooster programme, we provide you with all-round support.

Highly flexible.
A standardised system throughout all order series AE 001 to AE 004 allows significant cost reductions despite greater flexibility for the filler - optimum system utilisation, compatible with existing filling systems.

Highly recyclable.
Material recommendations for recyclable mono-PP or mono-PE pouches in the consumer goods industry.

Weldspouts (Filling through the weldspout)

Colour
Weiß, Natur, natur/weiß
Material
PP, PE, PE/PP
Order No. L mm B mm H1 mm Ø d mm Packaging unit
AE 001-37 NU 18,00 37,50 33,80 10,50 4.000
AE 002-40 N 20,00 40,00 33,80 12,50 3.000
AE 003-40 N 25,00 40,00 33,80 17,50 2.000
AE 004-50 N 29,00 50,00 33,80 21,50 1.500
AE 005-21 NU 16,00 21,50 29,80 8,50 8.000
AE 007-21 NU 13,80 21,50 28,80 8,50 8.000

Screw caps

Order No. Ø d mm H2 mm Tamper evident closure Packaging unit
C-AE 001 19,50 18,80 8.000
C-AE 001 O 19,50 18,80 x 8.000
C-AE 001 VSO Flower 33,00 18,80 x 3.000
C-AE 002 21,90 18,80 6.000
C-AE 002 O 21,90 18,80 x 6.000
C-AE 003 26,90 18,80 4.000
C-AE 003 O 26,90 18,80 x 4.000
C-AE 004 30,90 18,80 3.000
C-AE 004 O 30,90 18,80 x 3.000
C-AE 005 OF 17,50 18,40 x 8.000
C-AE 005 VSOF Flower 33,00 18,40 x 3.000
C-AE 007 VSO Clover 34,00 18,60 x 2.500
C-AE 001 O App-1 ASM 33,00 18,80 2.500

Assembled delivery (Weldspouts + Screw caps)

Order No. L mm B mm H3 mm Ø d mm Packaging unit
ZSB-AE 001-37 O 19,50 37,50 31,00 10,50 4.000
ZSB-AE 001-37 19,50 37,50 31,00 10,50 4.000
ZSB AE 002-40 21,90 40,00 31,20 12,50 3.000
ZSB AE 002-40 O 21,90 40,00 31,20 12,50 3.000
ZSB AE 003-40 26,90 40,00 31,20 17,50 2.500
ZSB AE 003-40 O 26,90 40,00 31,20 17,50 2.500
ZSB AE 004-50 30,90 50,00 31,20 21,50 1.500
ZSB AE 004-50 O 30,90 50,00 31,20 21,50 1.500
FAMAC® POUCHBOOSTER

There are many important benefits associated with our spouts and closures, both for your filling process and for the consumer and recycling process:

Series Overview PouchBooster®.



Standardised dimensions across all series – the advantages at a glance:



  • Uniform. Uniform system for ready-to-order series AE 001 to AE 004.
  • Economic. Great cost reductions.
  • Flexibility. Higher flexibility for the filling company.
  • Effective. Effective system usage, compatible with current filling systems.
  • Process reliable. Outstanding machinability.
serienueberblick-pouchbooster

Excellent machinability.

hervorragende-maschinengaengigkeit

For even more significant cost reductions - the advantages at a glance:



  • Multifunctional. Different material combinations are possible.
  • Flexibility. Short set-up times, quick format changes and high flexibility.
  • Economical. Fast cycles up to 200 spout/minute (double lane).
  • Permanent. Solidly joined materials.

Intuitive design.

intuitives-design-ausgiesser

For even more consumer benefits and convenience - the advantages at a glance:



  • Convenient opening and closing of the cap.
  • Audible tearing of the tamper-evident ring.
  • Easy opening thanks to an optimised tamper-evident ring system and low opening force required.

Customised solutions.

for mono-material-options in the food and non-food sector - the advantages at a glance:



  • Individual material and colour designs according to customer requirements.
  • Outer contours can be achieved individually with low tooling costs and additional expenses.
  • Developments of special solutions for customer requirements.
individuelle-loesungen-kappen-ae

Options for Mono-PE-Pouches .

mono-pe-beutel-optionen-ausgiesser-sa

For recyclable mono-PE pouches of the food and non-food sector:



  • Weld-spouts in HDPE for thermal welding and ultrasonic welding.
  • Weld-spouts in low sealing PE for optimised melting temperature for welding in recyclable mono PE bags.
  • Screw caps in HDPE with and without tamper-evident closure.

Options for Mono-PP-Pouches.

For recyclable mono-PP pouches of the food and non-food sector:



  • Weld-spouts in PP for thermal welding and ultrasonic welding.
  • Screw caps in PP with and without tamper-evident closure.
mono-pp-beutel-optionen-ausgiesser

Post-Consumer-Recyclate Applications.

ausgiesser-Familienaufnahme-frei

Pöppelmann blue®: Use of recycling material:



  • Solutions with Post-Consumer-Recyclate for the Non-Food-Sector.
  • Emission reductions through the use of PCR materials.
  • Screw caps in PCR-PE and PCR-PP with and without tamper-evident closure.
  • Weld-spouts in PCR-PE and PCR-PP.

You have not been able to find the right product in our standard programme? We would be pleased to develop a customised solution in cooperation with you.
